MEDICAL
Omega Group delivers reliable solutions for the Medical Diagnostics Industry, Hybrid Operating Rooms (ORs), Patient Monitoring Systems and Mobility Devices, based on leading technologies in Control, Connectivity and Power.
Medical Diagnostics Industry Solutions
Hybrid Operating Rooms (ORs)
Patient Monitoring Systems
Dental Clinics
Aesthetic Lasers and Energy Devices
Respiratory & Critical Care
CROSS-INDUSTRY MEDICAL EXPERTISE
Since 1947, Omega Fusibili SpA has been synonymous of professional reliability, and engineering excellence. Today, Omega Group is a trusted partner in the Med-Tech industry, grants advanced solutions for Medical applications involved in hybrid operating rooms (ORs), patient monitoring systems, respiratory and critical care, dental clinics, and aesthetic medicine technologies.
We offer a comprehensive portfolio built around leading brands in switching and control components, high-performance connectivity, medical-grade power supplies, and secure power connection technologies such as IEC Lock. Our solutions are designed to meet the demanding requirements of modern healthcare environments, where performance, safety, and continuity are critical.
Omega Group provides advanced power solutions compliant with international medical standards, featuring low leakage current, high efficiency, and reliable performance in critical applications.
High-reliability connectors capable of tens of thousands—even up to one million—mating cycles, to customized cable assemblies manufactured in cleanroom conditions, using technologies ensuring durability, precision, and efficiency.
Our offering also includes ergonomic and highly reliable human-machine interface (HMI) solutions—such as footswitches, joysticks, and control systems—engineered for intensive use in demanding medical environments. In addition, our secure IEC Lock systems prevent accidental disconnections, ensuring uninterrupted power supply in operating rooms, ICUs, and diagnostic laboratories.
With deep expertise in standards such as IEC 60601-1, including 2 MOPP and 2 MOOP protection requirements, we ensure maximum safety for both patients and operators in direct patient environments.
At Omega Group, we go beyond distribution. We deliver tailored, value-added solutions that integrate seamlessly into medical devices and systems—helping manufacturers and healthcare providers enhance safety, reliability, and performance.
ODU Connectors
ODU Connectors is a German company that has been manufacturing high-performance electrical contacts and connectors for over 80 years. It currently offers specific connector lines for medical electrical applications that meet the requirements of the Medical Device Regulation (MDR), specifically IEC 60601-1.
The key feature of ODU electrical contacts (and complete connectors) is that they are designed to withstand tens of thousands of mating cycles over their lifetime, without maintenance.
ODU MINI-SNAP®
Circular plastic & metal connector
High voltage solutions for up to 1,000 V AC / 16 A
Up to 5,000 mating cycles
2-34 contacts. Up to IP68 rating
Quick mating with push pull locking
IEC 60601-1 compliant
ODU MEDI-SNAP®
Miniature circular connector
5,000 mating cycle and more
500 autoclaving cycles
Advanced electromechanical shielding option, 6 sizes, 3 termination types
Up to 250 V AC/DC, up to 16 A
Coax contact available
IEC 60601-1 compliant. Up to IP68
ODU MINI-MED®
Space-saving and compact product design
1,000 mating cycles and more
2 – 6 contacts, IP67
Cost-effective miniaturized solution including cable assembly with overmolding
ODU-MAC® PUSH-LOCK
Highly modular & customized hybrid connector solutions
Easy push‑pull locking
Handles signal, power, HV up to 6,300 V, RF, fluids, data, fiber optics
5,000–10,000 mating cycles
Simple, ergonomic use
ODU-MAC® ZERO
The only NON-MAGNETIC modular connector on the market, making it ideal for installation on MRI machines
4 different cable outlets: straight, right angle, 45° or in-line
Quick separation with snap-in locking
Break-away function / emergency release
Bio-compatibility upon request
Suitable for a wide range of ODU-MAC® modules including coax
Up to 60,000 mating cycles, Up to 70 contacts
FIBER OPTIC
Over up to 100,000 mating cycles
G0F (mutimode/singlemode) and P0F system solutions
Fiber only and hyrbrid systems
Available as a fully assembled solution
IP6K8 class in mated condition, IP68 and IP6K9K class also in unmated condition
Operating temp -40°C to +85°C
Expanded Beam and Phisical Contact technology
SILICONE‐OVERMOLDED SYSTEM SOLUTIONS
Hygienic and robust
Complies with DIN EN ISO 10993-5
new surface with unique haptics
no stick-slip effect
CUSTOMIZED OVERMOLDING
Economical
Cost-effective tools
Customized overmolding
Global availability
Fast delivery
HIGH SPEED DATA TECHNOLOGY
Analog and digital signals
Reliable and innovative solutions for modern high-speed data transmission
Highest contact safety for reliable transmission in the high-frequency range
EEPROMs for smart communications in the operating room
HIGH DENSITY TECHNOLOGY
High-density technology allows the maximun number of contacts in the smallest possible space
Despite their small footprint, the contacts’ dependability and robustness are guaranteed
EMC SHIELDING
Advanced EMC (Electromagnetic Compatibility) shielding solutions
Designed to ensure signal integrity and protect connections from external electromagnetic interference (EMI)
CABLE ASSEMBLIES AND SYSTEM SOLUTIONS
Reliable First-class, customized cable assembly – including under class 9 cleanroom conditions
Space-saving arrangement of hoses, cables and plugs for device modules
Large selection of cables and third-party products in stock for immediate processing
ODU SPRINGTAC contact
Maximum number of contact points
Up to 1 million mating cycles
Low mating and demating forces
High vibration and shock resistance
Low contact resistance
High current-carrying capacity
CUSTOMIZED SOLUTIONS
Special insulator, designed in accordance with IEC 60601-1
Implementation of clearance and creepage distances
To satisfy specific customer requirements in the low-voltage and high-voltage range
100% NON-MAGNETIC
Many different standard products in catalogue
Certified as Amagnetic components
Suitable for installation on MRI machines
HERGA Industrial Foot Switches
Herga’s product portfolio includes a wide range of single and multi‑pedal footswitches, available with electrical, pneumatic (air), Bluetooth wireless and USB interfaces, suitable for industrial, medical, commercial and OEM applications.
Herga footswitches are engineered for durability, comfort, and safety, with options for custom colours, logos, cable configurations, and protective bases. Many products are certified to industry standards such as IEC/UL 60601-1 for medical use and offer high ingress protection ratings (IPX2 to IPX8), making them suitable for harsh environments.
USB FOOTSWITCH
UL 60601-1 approved
1, 2 or 3 switch foot pedal or hand
control
Plug & play technology, no additional
drivers required
Windows™, Linux™ & Mac™ OS
Waterproof versions to IPX8 possible
BLUETOOTH FOOTSWITCH
UL 60601-1 approved; accessible battery
compartment
1000+ hours use; LED battery indicator
Range up to 10 m
Custom colors/logos
IPX7 (IPX8 on request); 2 × AAA batteries
MD FOOTSWITCH SERIES
UL 60601-1 approved
Combines electrical and pneumatic switches with high flexibility
Combines standard electrical footswitches and puck (bellows) switches
IPX7 protection (IPX8 on request)
PNEUMATIC SWITCH
PVC Housing
100mm diameter
Operating temperature +10°C to +40°C
Available with or without a mounting
base
ELECTRIC HAND CONTROL
Ergonomic design with large, easy-to-use buttons
Available in IP54 or IP68 versions
Interlockable switches
Lightweight construction
Large, robust hook available
PNEUMATIC HAND CONTROL
2, 4 & 6 way variants available
Ergonomic, comfortable design with softtouch buttons
Curly or straight tubing
Multiple colour and layout options
Compatible with 6891 airswitches
Fully waterproof
COSEL Power Solutions
COSEL is a Japanese company that has been manufacturing power supplies, AC/DC switching devices, DC/DC converters, and filters for nearly 60 years.
Distinctive features include high quality, reliability, energy efficiency, and durability, along with high safety standards, often complying with international regulations for medical devices.
PCA SINGLE OUTPUT
Medical Safety Approvals
(ANSI/AAMI ES60601-1, EN60601-1 IEC60601-1-2 4th Ed.)
Leakage Current (0.50mA MAX)
Low Profile (41mm) for 1U Applications
Output Voltage Adjustable to near 0VDC
Remote Monitoring via Communication Interface, Alarm Function
AUX (Selectable Voltage Range 5V-12V)
Digital Interface RS232 or PMBus
AEA BF RATED
Small Foot Print, High Power Density
Medical Safety Standards ES60601-1, EN60601-1 3rd Edition, UL62368-1
Leakage current 3 mA @240 VAC
Output Voltages 24V to 48VDC
High Peaking up to 3 times convection
rating
Less than 1U high (600W only)
GMA BF RATED
2″ X 4″ Industry Standard footprint
Medical Safety Standards
ES60601-1, EN60601-1 3rd Edition,UL62368-1
Leakage current 13/30 100/240
Output Voltages 12V to 56VDC
AC/DC 2MOPP BF RATED UMA BF RATED
2″ X 3″ Industry Standard footprint
Medical Safety Standards ES60601-1, 3rd Edition
UL62368-1
Leakage current 0.2/240 VAC
Output Voltages 5V to 48VDC
MH SERIES PCB MOUNT
High Isolation up to 3KV
2 MOOP
Wide Input Range 4:1
Remote On/Off
UL62368-1, EN62368-1, EN60601-1 3RD Ed
SIP 8 Foot Print
Output Voltage Adjustment
OCP Auto-Recovery
Output 3.3 to 15 VDC and +/-12 & 15 VDC
COSELSYNC. CXLA Series
AC-DC Medical Adapter (BF)
AV & ICT, and Medical Safety Approval: IEC62368-1, IEC60601-1 Ed. 3.2. 2 x MOPP Extremely Low Leakage Current
Efficiency: Compliant with DoE Level VII
No-load ≤ 0.15 W
Wide Operation Temperature Range: -30 °C to 70 °C (with power derating)
Interfaces: AC Input C14, C8, C6. DC Output Plug Type: 5.5×2.5 Barrel Straight, Min. DIN 4P with Lock, Others
APEM HMI Solutions
APEM is a globally recognized company specializing in the design and manufacturing of high-quality human-machine interface (HMI) components. Founded in 1952 and headquartered in France, APEM has built a strong reputation for innovation, reliability, and precision engineering. The company offers a wide range of products, including switches, joysticks, keypads, and indicator lights.
APEM is part of the IDEC Corporation group, which strengthening its global presence and technological capabilities.
With manufacturing facilities and offices around the world, APEM is able to serve customers internationally while maintaining high standards of quality and performance.
PBA: METAL PIEZO SWITCH
Diam. 16, 19, 22 or 30 mm bushing
Sealed to IP68 or IP69K
Easy to clean metal surface
Long life (50 million cycles)
Ring or dot illumination
Custom configurations
IX: COMPACT NO/NC
12 mm diameter compact bushing
Flexible elastomer membrane actuator
Recommended for harsh environments
Illuminated or non-illuminated
Sealing : IP67, IP69K
Marking on request
METAL PIEZO KEYPADS
In standard 12 keys. Smooth aluminum front face for a modern design
Easy to clean. Protected against water, dust and frost.
Wear-free, no consumption
No risk of unintentional activation by wind or water
MEMBRANE SWITCH PANELS
Entirely customizable graphic design
Tactile feedback: integration of snap domes with different forces
Visual feedback by integration of LEDs
Indestructible marking printed on rear of upper polyester layer
Sealing up to IP65/IP67 and resistance to salt spray
Long life: up to 1 million cycles
Connection and output interface: choice of connector and pitch
MINI JOYSTICK NV Series
Ultra compact navigator with strong tactile feedback
4 or 5-direction switch-based joystick (4 directions + pushbutton)
Bushing Ø 16 mm
Sealed to IP69K
Robust: shock, vibration and salt spray resistant
MINI JOYSTICK TS Series
TS series thumbstick
Proportional two axis joystick in a miniature package
Available with USB output and illuminated ring
Non-contact Hall-effect technology
IP67 above panel sealing
Redundant outputs available
IP SERIES Switches
Versatile range easy to customize
Illuminated or non-illuminated momentary action pushbuttons
Sealed to IP67
Round or square actuator
Numerous terminal options, gold plated silver contacts
AV SERIES: metal and robust push button switch
Ø 16, 19, 22 or 30 mm
Momentary (NO) or NC/NO
Actuator and bushing : nickel plated, chrome plated, varnished polishedor stainless steel
Flat or curved actuator available
Marking and illumination available
Front panel sealing : IP65
TOGGLE SWITCHES
Up to a 3 positions switch, with momentary or alternate functions
PCB solder lugs, quick-connect or wire wrap termination options
Numerous ratings, sealing, lever finish options and sealing boots
E-STOP Switches
Emergency Stop Switches
Ø 16 and 22 mm
Front sealing : IP65
Approved according to EN 60947-5-1, EN 60947-5-5
Illuminated or not-illuminated
ROCKERMEC Switch Solution
Consists of two Multimec™ 5E switches, a sealing that also provides functionality and a rocker cap called 10A
Small dimension 10.6 x 28 mm, h=12.15
Panel sealed to IP67
Lifetime (Sealing): 500,000 cycles
Standard cap colors: grey, red, black and frosted white
Standard legend options available
Available as a module
ULTRANAVIMEC™ Navigation Solution
Ideal for applications where space is limited
Five positions: a select button in the middle and four navigational positions
LED illumination via PCB-mounted chip
Compact solution Ø22.14, h=7.15 mm
IP67. 500,000 activations
Standard cap colors: blue, grey, red, black, signal white and frosted white.
Standard legend options available
Available as a module
INDUSTRIAL INDICATORS: (LB/LBW series)
IP65 LED sealing
Ø 22 mm (LBW), 18 mm (LB flush) and 16 mm (LB)
Up to 3 contacts (silver-gold plated) up to 5 A
Fully qualified: UL, CE, TUV, CCC, CSA
Q SERIES LED INDICATOR
5 mm flush diffused LED, standard, hyper bright or water clear
Flush chamfered bezel style (200 mm long)
Available in RGB
IP67 sealing option (EN60529)
Temperature Range: -40 °C to +85° C
Life Expectancy: 100,000 hours
Stainless Steel 316L
3000 SERIES
1, 2, or 3 axis analog
PWM, CAN J1939, CANopen
Low profile (less than 20 mm below panel)
-25 °C to +70 °C. 5 V or 3.3 V
IP66. Mechanical life: 10 million cycles
EMC Emissions Level: EN61000-6-3:2001, CISPR 22:2005, Class B 30 MHz-11GHz
ESD: EN61000-4-2 (extended)
IEC Lock by Scolmore
IEC Lock by Scolmore, an international group specializing in high-quality solutions, is the patent holder for IEC Lock technology, developed to increase the safety and reliability of power connections.
IEC Lock cables feature a patented locking mechanism that prevents accidental disconnection of the plug from the IEC socket, ensuring a stable and continuous power supply. Compared to standard IEC cables, IEC Lock models are designed to withstand vibrations or accidental pulls, drastically reducing the risk of accidental disconnections in environments such as operating rooms, intensive care units, or diagnostic laboratories.
POWER CORDS
C13 or C19 sockets with locking system
International plugs, also 90° version
Cables colors: black, red, orange, blue, white
C13 REWIRABLE SOCKET
Current/Voltage: 10A 250V
Wireable
Compact size
Also 90° version
C13-C19 PANEL MOUNTING SOCKETS
C13- Current/Voltage: 10A 250V
C19- Current/Voltage: 16A 250V
Locking system, multi-tier modules available
C19 + REWIREABLE CONNECTOR
Rear Release Locking Mechanism
Rewireable. Anti-Vibrate
Fits any standard C20 inlet. Easy pull handle
16A Max / 250V~ (Europe & Australia)
20A Max / 250V~ (USA)
Slotted and Cross head housing screws
Appliance inlet suitable for cold conditions
CX PANEL MOUNT CONNECTOR
Secure Locking Side and Bottom Tabs
10A,15A, 16A, 20A (125v-250v)
Used on PDUs, servers and most network devices
Designed to fit 1.5mm panels
Will sit alongside the current PA13 and PA19 range
C14 IEC DUAL LOCKING CONNECTOR
Secure Locking Side and Bottom Tabs
Cannot be accidentally pulled or vibrated out of the outlet
A European, USA, Canada, Australian, and Japanese approved Dual Locking C14
10A / 250V~ (Europe & Australia)
15A / 250V~ (America, Canada & Japan)
OTHER MEDICAL SOLUTIONS
HIGH CURRENT CONTACTS
High Current Contact bush for tab contacts (standard) for PCB and lead frames
Applicable for Reflow soldering on PCB
Applicable for Laser welding on lead frame
With or without soldering pin
Approvals: LV215
CIRCULAR CONNECTORS M16, SERIE 03
Threaded joint (diameter 16 mm). Metal housing (nickeled)
IP40 / IP68, Solder terminals
IP68, Crimp contacts for 5;6;8; pin configuration – AISG
3 to 14 poles (flash gold-plated or gold-plated)
Rated current : up to 5 A
Rated voltage : up to 250V AC
MICROMODUL 1,27MM & RAST 1,5-2,5MM CONNECTORS
IDT (Insulation Displacement Technology) even in custom lenghts
From 4 to 26 contacts (Micromodul)
1,2A per contact @ 32 VAC. THT or SMT
Cable-to-board and cable to cable connections (RAST)
RAST standar keying prevents mismating
For signal and low load currents up to 3A (1,5mm) and 4 A (2,5mm)
ROTARY DC SOLENOIDS
Accurate position and speed control using PWM, suitable for sensitive medical devices
Low-noise, shock-free motion ideal for patient environments
Long life (>100 million cycles) enabling low maintenance and continuous operationng prevents mismating
For signal and low load currents up to 3A (1,5mm) and 4 A (2,5mm)
LINEAR TUBULAR SOLENOIDS
Delivers strong force for short strokes with long life (~25 million cycles)
Available in various sizes, push/pull configurations, and magnetic latching options
Resistant to shock and vibration, suitable for harsh environments and lock/latch applications
MICROSWITCHES
Ultraminiature, Subminiature and Miniature series
Comply with UL, EN, CSA, and CCC standards
Maximum Electrical Voltage 250 VAC
From IP40 to IP68
4000 SERIES BUCANEER
Miniaturized and versatile circular connector (19,7mm diam over coupling ring)
Quick-turn bayonet coupling mechanism to connect cable rapidly
Rated to IP66, IP67, IP68 & IP69K standards
3-12 contacts. Up to 13 A, 600 V AC/DC
Max cable O/D 7 mm
UL, CSA & VDE approvals
6000 SERIES BUCANEER
Circular connector with an easy to use 30 degree locking mechanism
Environmental sealing up to IP68 and IP69K
Available with rugged metal or plastic housings
2-22 contacts. Up to 16 A, 227 V AC/DC
Max cable O/D 10 mm
UL, CSA & VDE approvals
DATA CONNECTORS DUST AND WATERPROOF RANGE
Circular connector for USB applications
Mini-USB, Micro-USB, USB-C
IP66, IP67, IP68 & IP69K protection
Different configurations and locking style
Front + rear & PCB panel mount options
Single & double ended cable / panel mount options (1m, 2m, 3m, 5m)
CLASS CC & J FUSES
Class CC Fuses:
600 V, 200 kA interrupting rating
Size: 13/32” × 1 1/2”
Rejection design (prevents lower-rated fuses). Range: 0.1–30 A
Class J Fuses:
600 Vac, ≥200 kA interrupting rating
Current-limiting
Not interchangeable with other classes
BS88 FE FUSES
BS88 fuse (complies with British electrical safety standards)
BS88 (Part 1 and Part 2) and IEC 60269-1 / 60269-2
Wide variety of current ratings and nominal voltage options
Ensures safe and reliable circuit protection compatible with these standards
FUSE DISCONNECTOR CH SERIES
DIN-rail fuse holders for IEC 10×38 fuses
Available with or without indication
1, 2 , and 3-pole versions
IP20 finger-safe design
Wide range of accessories available
Can be ganged together for specific application needs
MOTORIZED ASSISTANCE
Swift electric help for medical gear. Hygienic design and stainless-steel suitable for clean rooms
AUTOMATION & MOTORIZATION
Electric traction with an IT system for autonomous and secure operations
SIMPLIFIED SOLUTIONS TO HELP HEALTHCARE WORKERS
DIRECT PATIENT ENVIRONMENT ACCORDING TO IEC 60601-1
Maximum patient and operator protection IEC 60601-1 sets out stringent requirements for protection against electric shock in medical applications in which patients and operators come into direct contact with electrical equipment and systems.
To reduce this risk to a minimum, manufacturers must always integrate two protective measures into their products:
2 MOPP (Means Of Patient Protection) > Protective measures for patients
2 MOOP (Means Of Operator Protection) > Protective measures for operators
The patient environment is the space in which intentional or unintentional contact can occur between the patient, the operator and parts of the Medical Electrical Equipment (ME Equipment).
A patient is a living being undergoing a medical, surgical, or dental procedure. This concept is related to the definition of an active medical device under the MDR (Medical Devices Regulation (EU) 2017/745). Compliance with IEC 60601-1 supports meeting relevant safety requirements of the MDR. The IEC 60601-1 standard applies to medical electrical equipment and systems intended for use in the patient environment, including those that may come into direct physical or electrical contact with the patient, or are located in the immediate vicinity of the patient. In applications where the equipment or systems are not intended to be used within the patient environment, protection of persons other than the patient (e.g., operators or medical staff) through two Means of Operator Protection (2 MOOP) is generally considered sufficient.
News
SPS Italy: the meeting point for industrial automation
Parma, May 26-28 2026Once again this year, Omega will take part in SPS Italia 2026, a key event for the industrial automation sector and for smart, digital and sustainable industry technologies.For Omega Fusibili, SPS Italia represents an important opportunity to meet...
Circuit Protection and Motion Control: Omega at MCE 2026
Mostra Convegno Expocomfort: Hall 9 – Booth L10 From March 24 to 27, Omega Fusibili will be exhibiting at Mostra Convegno Expocomfort 2026, one of the leading international events dedicated to energy technologies, HVAC and integrated systems, taking place at Fiera...
The First Trade Shows of 2026: two new highlights
The year 2026 for Omega Fusibili opens with two trade show debuts Progetto Fuoco in Verona and Key Energy in Rimini are our first fair commitments of the year. These events — a leading reference in the heating sector for the first, and in the energy efficiency and...
